Stronghold ICF FX-Series 8" 90° Corner Block
90° Corner blocks make up between 10%-20% of a typical ICF project. The FX Series 90° Corner blocks are made from 16" tall panels with a long leg and a short leg allowing for a standard 16" overlap. The 2.75” thick foam panels are a heavy 1.5lb density with reversible interlocking foam teeth along the top and bottom panel edges. The panels are held in a structural position with 6 fixed webs, spaced 8" apart. The corner web assembly consists of 2 vertical webs on each side and 2 horizontal 1.5" wide bands locked into the vertical webs and tied together with 2 diagonal straps that interlock with the webs on the inner corner for unparallelled strength and fastening capabilities.
8" FX 90° Corner Block
Core Width: 8" (203mm)
Form Width: 13.5" (343mm)
Long Leg Length: 42" (1067mm)
Short Leg Length: 26" (660mm)
Form Height: 16" (406mm)
Surface Area: 7.56sf (169cm^2)
Concrete Volume: 0.15yd^3 (0.114m^3)
90° Corner blocks make up between 10%-20% of a typical ICF project. The FX Series 90° Corner blocks are made from 16" tall panels with a long leg and a short leg allowing for a standard 16" overlap. The 2.75” thick foam panels are a heavy 1.5lb density with reversible interlocking foam teeth along the top and bottom panel edges. The panels are held in a structural position with 6 fixed webs, spaced 8" apart. The corner web assembly consists of 2 vertical webs on each side and 2 horizontal 1.5" wide bands locked into the vertical webs and tied together with 2 diagonal straps that interlock with the webs on the inner corner for unparallelled strength and fastening capabilities.
8" FX 90° Corner Block
Core Width: 8" (203mm)
Form Width: 13.5" (343mm)
Long Leg Length: 42" (1067mm)
Short Leg Length: 26" (660mm)
Form Height: 16" (406mm)
Surface Area: 7.56sf (169cm^2)
Concrete Volume: 0.15yd^3 (0.114m^3)
90° Corner blocks make up between 10%-20% of a typical ICF project. The FX Series 90° Corner blocks are made from 16" tall panels with a long leg and a short leg allowing for a standard 16" overlap. The 2.75” thick foam panels are a heavy 1.5lb density with reversible interlocking foam teeth along the top and bottom panel edges. The panels are held in a structural position with 6 fixed webs, spaced 8" apart. The corner web assembly consists of 2 vertical webs on each side and 2 horizontal 1.5" wide bands locked into the vertical webs and tied together with 2 diagonal straps that interlock with the webs on the inner corner for unparallelled strength and fastening capabilities.
8" FX 90° Corner Block
Core Width: 8" (203mm)
Form Width: 13.5" (343mm)
Long Leg Length: 42" (1067mm)
Short Leg Length: 26" (660mm)
Form Height: 16" (406mm)
Surface Area: 7.56sf (169cm^2)
Concrete Volume: 0.15yd^3 (0.114m^3)
